-This is a 370WG worm gear DC motor with zinc alloy aluminum housing and pure copper turbine and worm inside for increased durability.
-You can change the motor's rotation direction by changing the motor wiring to positive or negative, and with full metal gears, low noise and self-locking function.
Rated Voltage: 12V DC; Gear Ratio: 37.3; Speed: 160 RPM; Torque: 0.55 kg.cm; Shaft: D Shaft; Shaft Diameter: 6mm; Shaft Thread Diameter: 3mm * 12mm; Overall Shaft Length: 14mm;
Applications: Label machines, remote control curtains, automatic voltage regulators, barbecue grills, ovens, washing machines, waste disposal machines, household appliances, coin machines, bill recognition devices, automatic actuators, coffee machines, towel machines, printing machines, stage lighting. This section is suitable for small motor configurations with high speed ratios, limited installation space, and large torque output.
-Speed, voltage can be designed according to your requirements. If you need other models of motors, please contact us by email. Welcome to bulk purchase and OEM orders!
-This is a 370WG worm gear DC motor with zinc alloy aluminum housing and pure copper turbine, with the worm inside for increased durability.
-You can change the motor wiring to change the motor direction of rotation to positive or negative.
1. Turbo worm gear motor is self-locking, that is, when there is no electricity in the motor, the output shaft will not rotate, that is, it is self-locking, and the self-locking force does not exceed 1.2 times the rated torque.
2. The direction of the output shaft of the gearbox is arranged perpendicular to the motor shaft, and the direction of the output shaft of the entire motor body is a required installation size.
Considering the above characteristics, worm gear motors are widely used in window openers, door openers, miniature winches and other applications.
-specification:
Rated voltage: 12V DC;
Gear ratio: 37.3;
Speed: 160RPM;
Torque: 0.55kgf.cm;
Shaft: D shaft;
Shaft diameter: 6mm;
Shaft internal thread diameter: 3mm*12mm;
Overall shaft length: 14mm;
-application:
Label machines, remote control curtains, automatic voltage regulators, BBQ grills, ovens, washing machines, waste disposal machines, home appliances, coin machines, banknote recognition devices, automatic actuators, coffee machines, towel machines, printing machines, stage lighting.
This section is suitable for small motor configurations with high speed ratios, limited installation space, and large torque output.
